Specification

• Printer Model

  GP-1125T

• Print Method

  Thermal Transfer / Direct Thermal

• Print Speed(inch/s)

  2~5 inch/s

• Interface

  Serial+USB+Parallel+Ethernet

• Print Resolution

  203 DPI

• Print Density

  0.125×0.125 mm (1 mm = 8 dots)

• Print Width

  104 mm(4.25")

• Print Length

  2286 mm(90")

• Print Head

  50KM

• Printer Dimensions

  285mm(L) x 210mm(W) × 180mm(H)

• Print Weight

  2.09KG

• Memory

  Flash: 4MB RAM: 8MB

• Font Size

  Font 0 to Font 8

• Power supply

  Input: AC 100-240V，50~60Hz
  Output: DC 24V 2.5A

• Media Roll Diameter

  Inside:127mm(5") Max.
  Outside:214mm(8.4") Max.

• Media Width

  120 mm(4.72") Max. ; 20 mm(0.78") Min.

• Media Roll Core Size

  25.4 mm~38 mm(1"~1.5")

• Media type

  Continuous paper, label paper with gap, fan fold label paper, black mark paper

• Media rolling up method

  Printing side outward rolling / inward rolling

• Media Length

  10~2286mm(0.39"~90")

• Ribbon Diameter

  67mm Max.

• Ribbon Length

  300m Max.

• Ribbon Core Size

  1 inch (25.4 mm)

• Ribbon Width

  110 mm Max. 30 mm Min.

• Enlargement&Rotation

  1 to10 times enlargement in both directions; 0°、90°、270°、360°rotation

• Work environment

  Temperature 5~45℃ (41~113℉), humidity 25~85%

• Storage environment

  Temperature -10~50℃ (14~122℉), humidity 10~90%

• Emulation

  TSPL
