Specification

• Printer Model

  GP-3150TIN

• Print Method

  Direct thermal

• Print Speed(inch/s)

  3~6inch/s

• Interface

  Interface

• Print Resolution

  203 dpi

• Print Density

  156mm(W) x 230mm(L) x 147mm(H)

• Print Width

  72mm Max.

• Print Length

  10~2286mm(0.39"~90")

• Print Head

  50KM

• Printer Dimensions

  230(L) x 156(W) x 147(H)mm

• Print Weight

  1.65KG

• Memory

  Flash: 4MB RAM:8MB

• Font Size

  Font 0~Font 8

• Power supply

  Input: AC 110V/220V, 50～60Hz
  Output: DC24V/2.5A

• Media Roll Diameter

  100mm

• Media Width

  25~80mm

• Media Roll Core Size

  25.4 mm~38 mm(1"~1.5")

• Media type

  Thermal paper

• Media rolling up method

  Inward rolling

• Media Length

  10~2286mm(0.39"~90")

• Ribbon Diameter

  N/A

• Ribbon Length

  N/A

• Ribbon Core Size

  N/A

• Ribbon Width

  N/A

• Enlargement&Rotation

  1 to10 times enlargement in both directions; 0°、90°、270°、360°rotation

• Work environment

  Temperature 5~45℃ (41~113℉), humidity 10~80% 10~80%

• Storage environment

  Temperature -10~50℃ (14~122℉), humidity 10~90%
