Specification

• MODEL

  GP-M324

• Printing Method

  Direct Thermal

• Printing Command

  TSPL, CPCL

• Resolution

  203DPI

• Printing Speed

  60mm/s (MAX)

• Printing Width

  72mm

• Print Head Temperature Detection

  Thermistor

• Print Head Position Detection

  Micro switch

• Paper Detection Sensor

  Opposite Sensor, Reflective Sensor

• Sensor Position

  Left side

• Display

  128×64 OLED

• Buttons

  Power/Save, Feed/Setup, Menu

• Communication Interface

  USB+Bluetooth

• USB Port Specification

  Type-C

• USB VID PID

  VID: 0471 PID: 0055

• Maximum Printing Size

  72 mm × 300 mm

• Graphics

  Monochrome PCX, BMP image file printing

• QR Code

  QRCODE, PDF417

• Character Set

  Simplified Chinese (GB18030): 16*16, 20*20, 24*24 Traditional Chinese (BIG5): 24*24, Korean (KSC5601): 24*24

• Character Magnification/Rotation

  Horizontal and vertical magnification 1-10 times Rotation printing (0°, 90°, 180°, 270°)

• Paper Type

  Continuous paper, Label paper, Reverse black label paper

• Medium Width

  25-80mm

• Paper Thickness

  0.06mm-0.17mm

• Paper Roll Outer Diameter

  51mm

• Paper Output Method

  Top output

• Power Supply

  Input: DC 5V 1A

• Charging Time

  ≤3h

• Battery Standby Time

  ≥72h

• Battery Printing Distance

  ≥200m (12.5% print density) (25°C)

• Battery Cycle Life

  400 times, ≥80%

• Battery Capacity

  7.4V/2000mAh

• Net Weight

  360g

• Dimensions

  114mm(W) * 112mm(D) * 60mm(H)
