Product Center

Overview

Introduction

Warehouse management is a critical component of modern supply chains, and industrial barcode printers with 300dpi resolution are providing exceptional solutions for this crucial task.

Advantages and Benefits

Enhancing Label Quality
1. High-Resolution Printing: Industrial barcode printers with 300dpi are known for their high-resolution printing capability, enabling the generation of clear and easily readable labels. This is crucial for accurate tracking and management within warehouse environments.
2. High-Quality Labels: Labels produced by these printers exhibit outstanding quality, capable of withstanding wear and environmental impacts, ensuring labels remain clear and legible throughout the transportation and storage of goods.
Boosting Efficiency
1. Automated Label Generation: Industrial barcode printers with 300dpi can be integrated with warehouse management systems for automated label generation. This reduces the workload of manual label creation and minimizes the potential for errors.
2. Rapid Printing Speed: These printers typically feature high-speed printing capabilities, allowing for the rapid generation of a large number of labels in a short amount of time, making them suitable for large-scale warehouse operations.
Providing Accuracy and Traceability
1. Precise Identification: High-resolution labels and barcodes offer more accurate identification, helping to reduce errors and enhance the traceability of goods management.
2. Inventory Management: Industrial barcode printers with 300dpi assist warehouses in accurately tracking inventory, ensuring that items are located precisely when needed.
Cost Reduction
1. Error Reduction: Through automated label generation and high-quality labels, these printers reduce human errors, lowering the additional costs associated with mistakes.
2. Consumable Replacement Reduction: High-quality labels are durable, reducing the frequency of label replacements and thus lowering related costs.
Industrial barcode printers with 300dpi resolution are the ideal solutio

Specification

• MODEL

  GI-2408T

• Level

  Standard

• Resolution

  GI-2408T: 8 dots/mm (203DPI)
  GI-3406T: 12 dots/mm (300DPI)

• Printing Method

  Thermal Transfer & Direct Thermal

• Max. print speed

  GI-2408T: 203mm(8")/second
  GI-3406T: 152mm(6")/second

• Max. print width

  GI-2408T: 104 mm (4.09")
  GI-3406T: 108.4mm (4.2")

• Max. print length

  GI-2408T PLUS: 15,000 mm (600")
  GI-3406T PLUS: 6,000 mm (270")

• CPU

  400 MHz, 32 bits, ARM9

• Memory RAM

  128 MB SDRAM

• Memory ROM

  128 MB Flash

• Interface

  • USB 2.0 High Speed 480Mbps
  • USB Host 2.0, for scanner or PC keyboard
  • RS-232
  • Internal Ethernet 10/100Mbps
  • Internal Bluetooth 4.0 (factory option)
  • Internal Wi-Fi (factory option)

• Real Time Clock

  Standard

• Buzzer

  Standard

• Dealer options

  • Guillotine cutter(full cut or partial cut) •Peeler

• Sensors

  • Gap transmissive sensor (position adjustable)
  • Black mark reflective sensor
  • Head open sensor
  • Ribbon out sensor
  • Label end sensor
  • Label begin sensor

• Power

  Internal universal switching power supply, Input: AC 200-240V，1.5A，50-60Hz， Output: DC 24V，5A，120W

• User Interface

  • 1 power switch
  • 2 buttons (Feed & Pause)
  • 4 LEDs (Online, Error, Ribbon, Communication status)

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need to download scalable font file)

• 1D Barcode

  Code 11，Code 39，Code 93，Code 128 (subsets A，B，C)，UPC-A，UPC-E，UCC-128，Codabar，EAN/JAN-8，EAN/JAN-13，Interleaved 2 of 5，ITF14，MSI Pleassy，PostCode，Telepen

• 2D Barcode

  QR Code，Micro QR Code，PDF417，Micro PDF417，MaxiCode，Aztec Code，Data Matrix

• Rotation

  Font and barcode support 0，90，180，270 degree

• Printer language

  Compatible to TSPL，EPL，EPL 2，ZPL，ZPL II，DPL

• Ribbon

  450 meters long, max. OD 105 mm, 1" core (ink coated outside)

• Ribbon width

  Max.115 mm (4.5")

• Media type

  Continuous, die-cut, black mark, fan-fold (outside wound)

• Media width

  20 ~ 120 mm (0.78"~ 4.72")

• Media thickness

  0.06 ~ 0.254 mm (2.36~10 mil)

• Media core diameter

  25.4 ~76.2 mm (1"~ 3")

• Label roll capacity

  203mm (8") OD

• Label length

  GI-2408T: 5~2,286 mm (0.2"~90")
  GI-3406T: 5~1,016 mm (0.2"~40")

• Physical dimension

  425mm(L) x 255mm(W) x 265mm(H)

• Net Weight

  9.65kg

• Enclosure

  Die-cast based print mechanism and metal cover with large clear media view window

• Safety regulation

  FCC Class A，CE Class A，CCC，BIS，CB

• Environment condition

  Operation: 5 ~ 40°C, 25 ~ 85% non-condensing, Storage: -40 ~ 60°C, 10 ~ 90% non-condensing

• Environmental concern

  Comply with RoHS，REACH，WEEE

• Accessories

  • Driver and software CD
  • Quick start guide
  • USB cable
  • Power cord

Operation film
