Specification

• MODEL

  GI-2408T PLUS; GI-3406T PLUS

• Level

  Empower

• Resolution

  GI-2408T PLUS: 8dots/mm(203DPI); GI-3406T PLUS: 12dots/mm(300DPI)

• Printing Method

  Thermal Transfer / Direct Thermal

• Max. print speed

  GI-2408T PLUS: 203mmm(8")/second; GI-3406T PLUS: 177.8mm(7")/ second

• Max. print width

  GI-2408T PLUS: 102 mm (4"); GI-3406T PLUS: 108.4mm (4.2")

• Max. print length

  GI-2408T PLUS: 15,000 mm (600"); GI-3406T PLUS: 6,000 mm (270")

• CPU

  400 MHZ, 32 bits, ARM9

• Memory RAM

  256 MB SDRAM

• Memory ROM

  256 MB Flash Memory

• Interface

  • USB 2.0 High Speed 480Mbps
  • USB Host 2.0, for scanner or PC keyboard
  • RS-232
  • Internal Ethernet 10/100Mbps
  • Internal Bluetooth 4.0 (factory option)
  • Internal WiFi (factory option)
  • I/O port (factory option)

• Real Time Clock

  Standard

• Buzzer

  Standard

• Dealer options

  • Guillotine cutter (full cut or partial cut)
  • Peeler

• Sensors

  • Gap transmissive sensor (position adjustable)
  • Black mark reflective sensor (position adjustable)
  • Head open sensor
  • Ribbon out sensor
  • Label begin sensor

• Power

  Internal universal switching power supply
  Input: AC 100-240V, 1.5A, 50-60Hz, Output: DC 24V, 5A, 120W

• User Interface

  • 1 power switch, 1 buttons (Feed), 1 LEDs (Online, Error, Ribbon status)
  • Capacitive Touch Screen, TFT LCD 4.3" 16 bits Color, 272 x 480 pixels, with back lights

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need download scalable font file)

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix

• Rotation

  Font and barcode support 0, 90, 180, 270 degree

• Printer language

  Compatible to TSPL, EPL, EPL 2, ZPL, ZPL II, DPL

• Ribbon

  450 M long, max. OD 105 mm, 1" core (ink coated outside)

• Ribbon width

  Max.110mm (4.3")

• Media type

  Continuous, die-cut, black mark, fan-fold (outside wound)

• Media width

  20~120 mm (0.78"~ 4.72")

• Media thickness

  0.06~0.254mm (2.36 ~ 10 mil)

• Media core diameter

  25.4 mm~76.2 mm (1"~3")

• Label roll capacity

  203 mm (8") OD

• Label length

  GI-2410T PLUS: 5~2,286 mm (0.2"~ 90"); GI-3406T PLUS: 5~1,016 mm (0.2"~40")

• Physical dimension

  444mm(L)*269mm(W)*339mm(H)

• Net Weight

  12.8kg

• Enclosure

  Die-cast based print mechanism/Metal cover with large clear media view window

• Safety regulation

  FCC Class A (Voltage specification is 110V, 200V is not supported), CE Class A, CCC, BIS, CB

• Environment condition

  Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing

• Environmental concern

  Comply with RoHS, REACH, WEEE
